TL1105BF250R
RoHS
/
Package /
Category Switches / Tactile Switches
Description
SWITCH TACTILE SPST-NO 0.05A 50V
PDF
/
Inventory: 8756
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Actuator Length 0.232 inch
Length - Termination 0.138 inch
Body Height 3.6068mm
Technical
Actuator Height off PCB, Vertical 9.50mm
Switch Travel 0.25mm
PCB Hole Count 4
Contact Rating @ Voltage 0.05A @ 50VDC
Outline 6.00mm x 6.00mm
Contact (DC) Max Rating R Load 0.05A@12VDC
Actuator Orientation Top Actuated
Operating Force 250gf
Switch Type KEYPAD SWITCH
Mechanical Life 100,000 Cycles
Illumination Non-Illuminated
Throw Configuration SPST
Electrical Life 100000 Cycle(s)
Dielectric Withstanding Voltage 250VAC V
Contact Current(DC)-Max 0.05A
Insulation Resistance 100000000Ohm
Contact Resistance 0.1mOhm
Switch Function Off-Mom
Circuit SPST-NO
Actuator Type Standard
Body Breadth 5.9944 mm
Body Length or Diameter 5.9944mm
Termination Style PC Pin
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series TL1105
Published 2006
Packaging Bulk
Operating Temperature -20°C~70°C
Physical
End Contact Plating GOLD
Center Contact Plating GOLD
Actuator Material Polyamide (PA), Nylon
Mounting Type Through Hole
Mount Through Hole
