TL1100FF160Q
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Tactile Switches
Description
Switch Tactile N.O. SPST Plunger PC Pins 0.05A 12VDC 1.57N Thru-Hole Bag
PDF
/
Buying Options
Total Price: USD $0.4
Unit Price: USD $0.4048
≥1 USD $0.4048
≥10 USD $0.38896
≥100 USD $0.374528
≥500 USD $0.323928
≥1000 USD $0.295178
≥3000 USD $0.273566
Inventory: 1303
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Contact Material Silver
Mount Through Hole
Mounting Type Through Hole
Actuator Material Polyester
Technical
Operating Temperature -20°C~70°C
Packaging Bulk
Published 2006
Series TL1100
JESD-609 Code e4
Feature Tactile Feedback
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
ECCN Code EAR99
Color Black
Voltage - Rated 12V
Voltage - Rated DC 12V
Orientation Straight
Current Rating 50mA
Termination Style PC Pin
Actuator Type Standard
Circuit SPST-NO
Switch Function Off-Mom
Contact Resistance 100mOhm
Insulation Resistance 100MOhm
Electrical Life 100000 cycles
Throw Configuration SPST
Illumination Non-Illuminated
Max Voltage Rating (DC) 12V
Mechanical Life 100,000 Cycles
Switch Type KEYPAD SWITCH
Contact Current Rating 50mA
Operating Force 160gf
Illumination Type Illuminated, Non-Illuminated
Actuator Orientation Top Actuated
Outline 12.00mm x 12.00mm
Contact Rating @ Voltage 0.05A @ 12VDC
Switch Travel 0.30mm
Actuator Height off PCB, Vertical 12.00mm
Dimensions
Length 12mm
Width 12mm
Actuator Length 7.1mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
