TL1015BF160QG
RoHS
/
Package SMD/SMT
Category Switches / Tactile Switches
Description
SWITCH TACTILE SPST-NO 0.05A 12V
PDF
/
Inventory: 9847
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Silver
Mount Surface Mount
Mounting Type Surface Mount
Package / Case SMD/SMT
Actuator Material Polyamide (PA46), Nylon 4/6
Technical
Operating Temperature -20°C~70°C
Packaging Tape & Reel (TR)
Published 2005
Series TL1015
Feature Board Guide
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Gull Wing
Voltage - Rated DC 12V
Packing Method TAPE AND REEL
Orientation Straight
Current Rating 50mA
Termination Style Gull Wing
Body Length or Diameter 4mm
Body Breadth 3 mm
Actuator Type Standard
Circuit SPST-NO
Switch Function Off-Mom
Contact Resistance 100mOhm
Contact Current(DC)-Max 0.05A
Electrical Life 50000 cycles
Throw Configuration SPST
Illumination Non-Illuminated
Max Voltage Rating (DC) 12V
Mechanical Life 200,000 Cycles
Switch Type KEYPAD SWITCH
Contact Current Rating 50mA
Operating Force 160gf
Illumination Type Illuminated, Non-Illuminated
Actuator Orientation Top Actuated
Contact (DC) Max Rating R Load .05A@12VDC
Outline 3.90mm x 2.90mm
Contact Rating @ Voltage 0.05A @ 12VDC
Switch Travel 0.20mm
Actuator Height off PCB, Vertical 2.00mm
Number of Switches 1
Dimensions
Body Height 1.5mm
Actuator Length 500μm
Compliance
REACH SVHC Unknown
RoHS Status RoHS Compliant
Lead Free Lead Free
