320.2E11BLKGRNLED
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Tactile Switches
Description
Tactile Switches Tactile PB BLK/GRN Cap
PDF
/
Inventory: 8178
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Actuator Material Polycarbonate (PC)
Technical
Operating Temperature -20°C~70°C
Packaging Bulk
Series 320
Feature Black Cap
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
Max Operating Temperature 70°C
Min Operating Temperature -20°C
Voltage - Rated DC 50V
Current Rating 25mA
Termination Style PC Pin
Actuator Type Rectangular Button
Circuit SPST-NO
Switch Function Off-Mom
Illumination Type, Color LED, Green
Throw Configuration SPST
Illumination Illuminated
Mechanical Life 1,000,000 Cycles
Operating Force 135gf
Illumination Type Illuminated, LED
Illumination Color Green
Actuator Orientation Top Actuated
Outline 12.40mm x 12.40mm
Contact Rating @ Voltage 0.025A @ 50VDC
Switch Travel 0.60mm
Actuator Height off PCB, Vertical 12.00mm
Compliance
RoHS Status ROHS3 Compliant
