320.22E11BLKWHT125
RoHS
/
Package /
Category Switches / Tactile Switches
Description
Square Button 320 Through Hole Top Actuated Tactile Switch 12.60mm 0.025A @ 50VDC 135gf -20C~70C
PDF
/
Inventory: 4829
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Through Hole
Actuator Material Polycarbonate (PC)
Technical
Operating Temperature -20°C~70°C
Packaging Bulk
Series 320
Feature Black Cap
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Style PC Pin
Actuator Type Square Button
Circuit SPST-NO
Switch Function Off-Mom
Illumination Non-Illuminated
Mechanical Life 1,000,000 Cycles
Operating Force 135gf
Actuator Orientation Top Actuated
Outline 12.40mm x 12.40mm
Contact Rating @ Voltage 0.025A @ 50VDC
Switch Travel 0.60mm
Actuator Height off PCB, Vertical 12.60mm
