320.21E11WHT
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Tactile Switches
Description
SWITCH TACT SPST-NO 0.025A 50V
PDF
/
Inventory: 5340
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Actuator Length 0.157 inch
Length - Termination 0.158 inch
Body Height 8.001mm
Technical
Actuator Height off PCB, Vertical 12.00mm
Switch Travel 0.60mm
Contact Function ON-OFF
PCB Hole Count 4
Contact Rating @ Voltage 0.025A @ 50VDC
Outline 12.40mm x 12.40mm
Contact (DC) Max Rating R Load 0.3A@50VDC
Actuator Orientation Top Actuated
Operating Force 135gf
Switch Type KEYPAD SWITCH
Mechanical Life 1,000,000 Cycles
Illumination Non-Illuminated
Electrical Life 1000000 Cycle(s)
Dielectric Withstanding Voltage 1000VRMS V
Contact Current(DC)-Max 0.3A
Insulation Resistance 1000000000Ohm
Contact Resistance 0.01mOhm
Switch Function Off-Mom
Circuit SPST-NO
Actuator Type Rectangular Button
Body Breadth 12.3952 mm
Body Length or Diameter 21.9964mm
Termination Style PC Pin
Orientation Vertical
Additional Feature WITHOUT GROUND TERMINAL
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature White Cap
Series 320
Packaging Bulk
Operating Temperature -20°C~70°C
Physical
End Contact Material COPPER ALLOY
Terminal Material COPPER ALLOY
Center Contact Material COPPER ALLOY
Actuator Material Polycarbonate (PC)
Housing Material NYLON
Surface Mount NO
Mounting Type Through Hole
Contact Plating Gold
Supply Chain
Factory Lead Time 10 Weeks
