320.02E11.08WHT
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Tactile Switches
Description
SWITCH TACT SPST-NO 0.025A 50V
PDF
/
Inventory: 5343
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Actuator Length 0.276 inch
Length - Termination 0.157 inch
Body Height 7.3914mm
Technical
Actuator Height off PCB, Vertical 14.40mm
Switch Travel 0.60mm
PCB Hole Count 4
Contact Rating @ Voltage 0.025A @ 50VDC
Outline 12.40mm x 12.40mm
Contact (DC) Max Rating R Load 0.25A@50VDC
Actuator Orientation Top Actuated
Operating Force 135gf
Contact Current Rating 25mA
Mechanical Life 1,000,000 Cycles
Max Voltage Rating (DC) 50V
Illumination Non-Illuminated
Throw Configuration SPST
Electrical Life 1000000 Cycle(s)
Dielectric Withstanding Voltage 500VRMS V
Contact Current(DC)-Max 0.25A
Insulation Resistance 1000000000Ohm
Contact Resistance 0.05mOhm
Switch Function Off-Mom
Circuit SPST-NO
Actuator Type Round Button
Body Breadth 12.3952 mm
Body Length or Diameter 12.3952mm
Termination Style PC Pin
Current Rating 25mA
Orientation Straight
Voltage - Rated DC 50V
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature White Cap
Series 320
Packaging Bulk
Operating Temperature -20°C~70°C
Physical
Terminal Material COPPER ALLOY
Actuator Material Polycarbonate (PC)
Mounting Type Through Hole
Mount Through Hole
Contact Plating Silver
Contact Material Copper, Silver
Supply Chain
Factory Lead Time 10 Weeks
