320.01E11GRY
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Tactile Switches
Description
SWITCH TACT SPST-NO 0.025A 50V
PDF
/
Buying Options
Total Price: USD $1.92
Unit Price: USD $1.9184
≥1 USD $1.9184
≥10 USD $1.580093
≥100 USD $1.472698
≥500 USD $1.150556
≥1000 USD $0.96646
Inventory: 986
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Contact Material Copper, Silver
Contact Plating Silver
Mount Through Hole
Mounting Type Through Hole
Actuator Material Polycarbonate (PC)
Technical
Operating Temperature -20°C~70°C
Packaging Bulk
Series 320
Feature Gray Cap
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
ECCN Code EAR99
Voltage - Rated DC 50V
Orientation Vertical
Current Rating 25mA
Termination Style PC Pin
Actuator Type Square Button
Circuit SPST-NO
Switch Function Off-Mom
Throw Configuration SPST
Illumination Non-Illuminated
Mechanical Life 1,000,000 Cycles
Switch Type PUSHBUTTON SWITCH
Contact Current Rating 25mA
Operating Force 135gf
Actuator Orientation Top Actuated
Outline 12.40mm x 12.40mm
Contact Rating @ Voltage 0.025A @ 50VDC
Switch Travel 0.60mm
Actuator Height off PCB, Vertical 10.00mm
Dimensions
Length 12.5mm
Width 12.5mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
