226EM1SABR
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Tactile Switches
Description
Rectangular Button 226E Surface Mount Right Angle Side Actuated Tactile Switch 4.70mm x 2.90mm 0.05A @ 12VDC 220gf -40C~85C
PDF
/
Inventory: 3726
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Actuator Length, Right Angle 3.55mm
Technical
Switch Travel 0.20mm
Contact Rating @ Voltage 0.05A @ 12VDC
Outline 4.70mm x 2.90mm
Actuator Orientation Side Actuated
Operating Force 220gf
Switch Type KEYPAD SWITCH
Mechanical Life 100,000 Cycles
Illumination Non-Illuminated
Switch Function Off-Mom
Circuit SPST-NO
Actuator Type Rectangular Button
Termination Style Gull Wing
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Tactile Feedback
Series 226E
Published 2015
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Mounting Type Surface Mount, Right Angle
Supply Chain
Factory Lead Time 12 Weeks
