PTS645VM15LFS
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Tactile Switches
Description
Tactile Switches N.O. SPST TACTILE SW PC PINS
PDF
/
Buying Options
Total Price: USD $0.12
Unit Price: USD $0.121587
≥1 USD $0.121587
≥10 USD $0.11601
≥100 USD $0.111604
≥500 USD $0.105047
Inventory: 93850
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 20 Weeks
Physical
Contact Material Bronze
Contact Plating Silver
Mount Through Hole
Mounting Type Through Hole, Right Angle
Actuator Material Polyamide (PA66), Nylon 6/6
Technical
Operating Temperature -20°C~60°C
Packaging Bulk
Published 2012
Series PTS645
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pins
Voltage - Rated DC 12V
Orientation Right Angle
Depth 19.8mm
Current Rating 50mA
Termination Style PC Pin
Actuator Type Standard
Circuit SPST-NO
Switch Function Off-Mom
Contact Resistance 100mOhm
Max Current Rating 50mA
Throw Configuration SPST
Illumination Non-Illuminated
Max Voltage Rating (DC) 12V
Mechanical Life 100,000 Cycles
Operating Force 160gf
Actuator Orientation Side Actuated
Outline 7.50mm x 7.10mm
Contact Rating @ Voltage 0.05A @ 12VDC
Dimensions
Length 7.5mm
Actuator Length 13.3mm
Actuator Length, Right Angle 15.85mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
