KSL1M511LFT
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Tactile Switches
Description
SWITCH TACTILE SPST-NO 0.05A 32V
PDF
/
Inventory: 3555
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings Dust Tight, IP60
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Actuator Length 6.2mm
Width 7.4mm
Length 7.4mm
Technical
Actuator Height off PCB, Vertical 9.90mm
Switch Travel 0.70mm
Contact Rating @ Voltage 0.05A @ 32VDC
Outline 7.40mm x 7.40mm
Actuator Orientation Top Actuated
Illumination Type Non-Illuminated
Operating Force 500gf
Mechanical Life 100,000 Cycles
Max Voltage Rating (DC) 32V
Illumination Non-Illuminated
Throw Configuration SPST
Max Current Rating 50mA
Switch Function Off-Mom
Circuit SPST-NO
Actuator Type Standard
Termination Style PC Pin
Current Rating 50mA
Depth 8.2mm
Ingress Protection IP60 - Dust Tight
Orientation Straight
Voltage - Rated DC 32V
Power Rating 1W
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Discontinued
Feature Grounding Pin
Series KSL
Published 2015
Packaging Tube
Operating Temperature -40°C~90°C
Physical
Mounting Type Through Hole
Mount Through Hole
Contact Plating Silver
Contact Material Silver
Supply Chain
Factory Lead Time 4 Weeks
