KSL0M412
RoHS
/
Package /
Category Switches / Tactile Switches
Description
Standard KSL MKII Through Hole Top Actuated Tactile Switch 9.90mm 50mA 50V 0.05A @ 32VDC
PDF
/
Buying Options
Total Price: USD $0.99
Unit Price: USD $0.9869
≥1 USD $0.9869
≥10 USD $0.931044
≥100 USD $0.878344
≥500 USD $0.828618
≥1000 USD $0.781719
Inventory: 1237
Minimum: 1
-
+
Technical Details
Compliance
Ratings Dust Tight, IP65, Water Resistant
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Actuator Length 6.2mm
Width 7.4mm
Length 7.4mm
Technical
Actuator Height off PCB, Vertical 9.90mm
Switch Travel 0.60mm
Contact Rating @ Voltage 0.05A @ 32VDC
Outline 7.40mm x 7.40mm
Actuator Orientation Top Actuated
Illumination Type Non-Illuminated
Operating Force 300gf
Contact Current Rating 50mA
Mechanical Life 100,000 Cycles
Max Voltage Rating (DC) 50V
Illumination Non-Illuminated
Throw Configuration SPST
Contact Resistance 50mOhm
Switch Function Off-Mom
Circuit SPST-NO
Actuator Type Standard
Termination Style PC Pin
Current Rating 50mA
Ingress Protection IP65 - Dust Tight, Water Resistant
Orientation Straight
Voltage - Rated DC 32V
Power Rating 1W
Min Operating Temperature -40°C
Max Operating Temperature 90°C
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series KSL MKII
Published 2003
Packaging Bulk
Operating Temperature -40°C~90°C
Physical
Mounting Type Through Hole
Mount Through Hole
Contact Plating Silver
Contact Material Silver
