KSL0M211
RoHS
/
Package /
Category Switches / Tactile Switches
Description
SWITCH TACTILE SPST-NO 0.05A 32V
PDF
/
Inventory: 9076
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Contact Material Silver
Contact Plating Silver
Mount Through Hole
Mounting Type Through Hole
Technical
Operating Temperature -40°C~90°C
Packaging Bulk
Published 2003
Series KSL
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
Max Operating Temperature 90°C
Min Operating Temperature -40°C
Power Rating 1W
Voltage - Rated DC 32V
Orientation Straight
Ingress Protection IP60 - Dust Tight
Current Rating 50mA
Termination Style PC Pin
Actuator Type Standard
Circuit SPST-NO
Switch Function Off-Mom
Throw Configuration SPST
Illumination Non-Illuminated
Max Voltage Rating (DC) 50V
Mechanical Life 500,000 Cycles
Contact Current Rating 50mA
Operating Force 130gf
Illumination Type Non-Illuminated
Actuator Orientation Top Actuated
Outline 7.40mm x 7.40mm
Contact Rating @ Voltage 0.05A @ 32VDC
Switch Travel 0.50mm
Actuator Height off PCB, Vertical 9.90mm
Dimensions
Length 7.4mm
Width 7.4mm
Actuator Length 6.2mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
Ratings Dust Tight, IP60
