KSC243J
RoHS
/
Package /
Category Switches / Tactile Switches
Description
Standard KSC Surface Mount Top Actuated Tactile Switch 3.50mm 10mA 0.01A @ 32VDC 300gf
PDF
/
Inventory: 1731
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Gold
Contact Plating Gold
Mount Surface Mount
Mounting Type Surface Mount
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Published 2003
Series KSC
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Orientation Vertical
Ingress Protection IP67 - Dust Tight, Waterproof
Termination Style J Lead
Actuator Type Standard
Circuit SPST-NO
Switch Function Off-Mom
Throw Configuration SPST
Illumination Non-Illuminated
Mechanical Life 300,000 Cycles
Contact Current Rating 10mA
Operating Force 300gf
Illumination Type Non-Illuminated
Actuator Orientation Top Actuated
Outline 6.20mm x 6.20mm
Contact Rating @ Voltage 0.01A @ 32VDC
Switch Travel 0.50mm
Actuator Height off PCB, Vertical 3.50mm
Dimensions
Length 6.2mm
Width 6.2mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
Ratings Dust Tight, IP67, Waterproof
