KSC223GLFG
RoHS
RoHS compliant
RoHS compliantPackage SMD/SMT
Category Switches / Tactile Switches
Description
SWITCH TACTILE SPST-NO 0.01A 32V
PDF
/
Buying Options
Total Price: USD $0.52
Unit Price: USD $0.5192
≥1 USD $0.5192
≥10 USD $0.5016
≥100 USD $0.469216
≥500 USD $0.407352
≥1000 USD $0.370691
≥3000 USD $0.343658
Inventory: 16671
Minimum: 1
-
+
Technical Details
Compliance
Ratings Dust Tight, IP67, Waterproof
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Actuator Length 900μm
Width 6.2mm
Length 6.2mm
Height 3.5mm
Technical
Actuator Height off PCB, Vertical 3.50mm
Switch Travel 0.35mm
Contact Rating @ Voltage 0.01A @ 32VDC
Outline 6.20mm x 6.20mm
Actuator Orientation Top Actuated
Illumination Type Illuminated, Non-Illuminated
Operating Force 160gf
Contact Current Rating 10mA
Mechanical Life 500,000 Cycles
Max Voltage Rating (DC) 32V
Illumination Non-Illuminated
Throw Configuration SPST
Max Current Rating 10mA
Switch Function Off-Mom
Circuit SPST-NO
Actuator Type Standard
Termination Style Gull Wing
Current Rating 10mA
Depth 10mm
Ingress Protection IP67 - Dust Tight, Waterproof
Orientation Straight
Voltage - Rated DC 24V
Power Rating 200mW
Number of Positions 2
Termination Gull Wing, SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series KSC
Published 2007
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Package / Case SMD/SMT
Mounting Type Surface Mount
Mount Surface Mount
Contact Material Gold
Supply Chain
Factory Lead Time 16 Weeks
