ATJG524VTR
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Tactile Switches
Description
SWITCH TACTILE SPST-NO 0.05A 12V
PDF
/
Inventory: 1830
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Contact Plating Silver
Mount Surface Mount
Mounting Type Surface Mount
Actuator Material Brass, Nickel Plated
Technical
Operating Temperature -25°C~70°C
Packaging Tape & Reel (TR)
Series ATJG
JESD-609 Code e4
Feature Grounding Pin
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
HTS Code 8536.50.90.40
Voltage - Rated DC 12V
Packing Method TAPE AND REEL
Current Rating 50mA
Termination Style J Lead
Body Length or Diameter 5.2mm
Body Breadth 5.2 mm
Actuator Type Flush
Circuit SPST-NO
Switch Function Off-Mom
Contact Current(DC)-Max 0.05A
Electrical Life 200000 Cycle(s)
Throw Configuration SPST
Illumination Non-Illuminated
Switch Type KEYPAD SWITCH
Operating Force 260gf
Actuator Orientation Top Actuated
Contact (DC) Max Rating R Load .05A@12VDC
Outline 5.20mm x 5.20mm
Contact Rating @ Voltage 0.05A @ 12VDC
Switch Travel 0.25mm
Actuator Height off PCB, Vertical 0.80mm
Number of Switches 1
Dimensions
Body Height 0.8mm
Compliance
RoHS Status ROHS3 Compliant
