ADTSM32SV
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Tactile Switches
Description
SWITCH TACTILE SPST-NO 0.05A 12V
PDF
/
Buying Options
Total Price: USD $0.57
Unit Price: USD $0.572
≥1 USD $0.572
≥10 USD $0.5544
≥100 USD $0.46288
≥500 USD $0.351965
≥1000 USD $0.307173
≥3000 USD $0.285842
Inventory: 766
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Actuator Length 0.059 inch
Body Height 3.5052mm
Technical
Body Color BLACK
Actuator Height off PCB, Vertical 5.00mm
Switch Travel 0.25mm
Actuator Color SALMON
Contact Rating @ Voltage 0.05A @ 12VDC
Outline 6.00mm x 3.50mm
Contact (DC) Max Rating R Load 0.05A@12VDC
Actuator Orientation Top Actuated
Operating Force 320gf
Illumination Non-Illuminated
Throw Configuration SPST
Electrical Life 50000 Cycle(s)
Dielectric Withstanding Voltage 250VAC V
Contact Current(DC)-Max 0.05A
Insulation Resistance 100000000Ohm
Contact Resistance 0.1mOhm
Switch Function Off-Mom
Circuit SPST-NO
Actuator Type Rectangular Button
Body Breadth 3.5052 mm
Body Length or Diameter 5.9944mm
Termination Style J Lead
Current Rating 50mA
Voltage - Rated DC 12V
HTS Code 8536.50.90.33
ECCN Code EAR99
Termination Gull Wing
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Tactile Feedback
Series ADTS3
Packaging Bulk
Operating Temperature -25°C~70°C
Physical
Terminal Material BRASS
Actuator Material Polyamide (PA), Nylon
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Silver
Supply Chain
Factory Lead Time 8 Weeks
