B82802A0012A215
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Switching Converter, SMPS Transformers
Description
B82802A For DC/DC Converters Surface Mount Flyback Converters For DC/DC Converters 100muH @ 100kHz 100kHz -40C~125C
PDF
/
Buying Options
Total Price: USD $4
Unit Price: USD $3.9952
≥1 USD $3.9952
≥10 USD $3.23752
≥100 USD $2.617472
≥500 USD $2.452208
≥1000 USD $2.342032
Inventory: 604
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mounting Type Surface Mount
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Series B82802A
Size / Dimension 0.650Lx0.681W 16.50mmx17.30mm
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type For DC/DC Converters
Applications Flyback Converters
Frequency 100kHz
Voltage - Isolation 1500Vrms
Voltage - Primary 36V~60V
Inductance @ Frequency 100μH @ 100kHz
Footprint 0.650 L x 0.902 W (16.50mm x 22.90mm)
Dimensions
Height Seated (Max) 0.341 8.65mm
Compliance
RoHS Status ROHS3 Compliant
