PH9496NLT
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Switching Converter, SMPS Transformers
Description
XFMR ISOLATION EP9 1:2.52 SMT
PDF
/
Buying Options
Total Price: USD $4.14
Unit Price: USD $4.1448
≥1 USD $4.1448
≥10 USD $3.35544
≥100 USD $2.712864
≥500 USD $2.541616
Inventory: 1063
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Height Seated (Max) 0.492 12.50mm
Technical
Intended Chipset ACPL-32JT, ACPL-302J
Voltage - Primary 8V~18V
Voltage - Isolation 2500Vrms
Frequency 80kHz
Applications Flyback Converters
Type For DC/DC Converters
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.413Lx0.406W 10.50mmx10.30mm
Published 2017
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 17 Weeks
