PH0809CNLT
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Switching Converter, SMPS Transformers
Description
PH08XXCNL For DC/DC Converters Surface Mount Tape & Reel (TR) For DC/DC Converters 200kHz~700kHz -40C~125C
PDF
/
Buying Options
Total Price: USD $17.79
Unit Price: USD $17.791108
≥1 USD $17.791108
≥150 USD $7.09885
≥450 USD $6.862528
≥1050 USD $6.744367
Inventory: 6634
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Mounting Type Surface Mount
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Series PH08XXCNL
Size / Dimension 0.850Lx0.970W 21.59mmx24.64mm
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Type For DC/DC Converters
Style Planar
Frequency 200kHz~700kHz
Voltage - Isolation 1500Vrms
Dimensions
Height Seated (Max) 0.378 9.60mm
Compliance
RoHS Status RoHS Compliant
