PH0807CNL
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Switching Converter, SMPS Transformers
Description
PH08XXCNL For DC/DC Converters Surface Mount Tray For DC/DC Converters 200kHz~700kHz -40C~125C
PDF
/
Buying Options
Total Price: USD $9.49
Unit Price: USD $9.4864
≥1 USD $9.4864
≥10 USD $7.26352
≥100 USD $6.15355
≥500 USD $6.05279
≥1000 USD $5.750114
≥3000 USD $5.68957
Inventory: 316
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Height Seated (Max) 0.368 9.35mm
Technical
Footprint 0.850 L x 0.970 W (21.59mm x 24.65mm)
Voltage - Isolation 1500Vrms
Frequency 200kHz~700kHz
Style Planar
Type For DC/DC Converters
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.850Lx0.970W 21.59mmx24.65mm
Series PH08XXCNL
Published 2016
Packaging Tray
Operating Temperature -40°C~125°C
Physical
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 11 Weeks
