PH0259NL image
Favorite
PH0259NL image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Transformers / Switching Converter, SMPS Transformers
Description Power Transformer 500Vrms Dual Prim. Single Sec. 85V/375V Prim. 24V/5V Sec. Through Hole
PDF
/
Inventory: 3575
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant
Radiation Hardening No

Dimensions

Height Seated (Max) 0.709 18.00mm

Technical

Intended Chipset TNY266/274
Chipset Manufacturer Power Integrations
Footprint 0.630 L x 0.720 W (16.00mm x 18.30mm)
Voltage - Primary 85V~375V
Element Configuration Dual
Voltage - Isolation 500Vrms
Frequency 132kHz
Power Rating 60W
Applications Flyback Converters
Type For AC/DC Converters
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.630Lx0.720W 16.00mmx18.30mm
Published 2013
Packaging Tube

Physical

Mounting Type Through Hole
Mount Through Hole

Supply Chain

Factory Lead Time 12 Weeks
