TPD6S300RUKR
RoHS
RoHS compliant
RoHS compliantPackage 20-WFQFN Exposed Pad
Category Circuit Protection / Surge Suppression ICs
Description
SURGE SUPP 8VC 2-CIRCUIT 20WQFN
PDF
/
Buying Options
Total Price: USD $1.95
Unit Price: USD $1.9536
≥1 USD $1.9536
≥10 USD $1.62448
≥100 USD $1.292896
≥500 USD $1.094016
≥1000 USD $0.928259
Inventory: 1173
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Thickness 750μm
Width 3mm
Length 3mm
Height 800μm
Technical
Voltage - Working 3.3V
Voltage - Clamping 8V
Threshold Voltage +2.3V
Supply Current-Max (Isup) 0.135mA
Adjustable Threshold NO
Analog IC - Other Type POWER SUPPLY SUPPORT CIRCUIT
Number of Circuits 2
Interface USB
Number of Channels 6
Temperature Grade AUTOMOTIVE
Supply Voltage-Max (Vsup) 4.5V
Base Part Number TPD6S300
Terminal Pitch 0.4mm
Supply Voltage 3.3V
Number of Functions 1
Terminal Form NO LEAD
Terminal Position QUAD
Technology Internal Switch
Capacitance 1.5pF
Applications USB OTG
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 20
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Physical
Number of Pins 20
Surface Mount YES
Package / Case 20-WFQFN Exposed Pad
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 6 Weeks
