MAX14572EUD+
RoHS
RoHS compliant
RoHS compliantPackage 14-TSSOP (0.173, 4.40mm Width) Exposed Pad
Category Circuit Protection / Surge Suppression ICs
Description
In a Pack of 2, Maxim MAX14572EUD+, Voltage Supervisor 14-Pin, TSSOP
PDF
/
Buying Options
Total Price: USD $6.72
Unit Price: USD $6.7232
≥1 USD $6.7232
≥10 USD $6.0764
≥100 USD $5.030942
≥500 USD $4.804862
≥1000 USD $4.380904
≥3000 USD $3.815618
Inventory: 2366
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Dimensions
Width 4.4mm
Length 5mm
Technical
Overvoltage Threshold 33V
Undervoltage Threshold 19.2V
Supply Current-Max (Isup) 0.7mA
Watchdog Timer No
Operating Supply Current 490μA
Analog IC - Other Type ANALOG CIRCUIT
Min Supply Voltage 4.5V
Max Supply Voltage 36V
Number of Circuits 1
Temperature Grade INDUSTRIAL
Base Part Number MAX14572
Terminal Pitch 0.65mm
Supply Voltage 24V
Number of Functions 1
Terminal Form GULL WING
Terminal Position DUAL
Technology Internal Switch
Max Power Dissipation 2.0513W
Subcategory Power Management Circuits
Applications General Purpose
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Number of Terminations 14
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Published 2013
Packaging Tube
Physical
Number of Pins 14
Surface Mount YES
Package / Case 14-TSSOP (0.173, 4.40mm Width) Exposed Pad
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 6 Weeks
