LTC4364CDE-1#PBF
RoHS
RoHS compliant
RoHS compliantPackage 14-WFDFN Exposed Pad
Category Circuit Protection / Surge Suppression ICs
Description
SURGE STOPPER W/DIODE 14DFN
PDF
/
Buying Options
Total Price: USD $8.74
Unit Price: USD $8.7384
≥1 USD $8.7384
≥10 USD $7.89184
≥100 USD $6.533956
≥500 USD $6.240265
≥1000 USD $5.689649
≥3000 USD $4.955509
Inventory: 381
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 3mm
Length 4mm
Height Seated (Max) 0.8mm
Technical
Voltage - Working 4V~80V
Voltage - Clamping Adjustable
Supply Current-Max (Isup) 0.75mA
Adjustable Threshold YES
Analog IC - Other Type POWER SUPPLY SUPPORT CIRCUIT
Number of Circuits 1
Number of Channels 1
Supply Voltage-Min (Vsup) 4V
Temperature Grade COMMERCIAL
Supply Voltage-Max (Vsup) 80V
Operating Temperature (Max) 70°C
Qualification Status Not Qualified
Pin Count 14
Base Part Number LTC4364
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 0.5mm
Supply Voltage 12V
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form NO LEAD
Terminal Position DUAL
Technology External Switch
Subcategory Power Management Circuits
Additional Feature RESET THRESHOLD VOLTAGE IS 2.2 VOLT
Applications Automotive
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 14
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Published 2011
Packaging Tube
Physical
Number of Pins 14
Surface Mount YES
Package / Case 14-WFDFN Exposed Pad
Mounting Type Surface Mount
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 2 weeks ago)
Factory Lead Time 8 Weeks
