LT4356HMS-1#PBF
RoHS
RoHS compliant
RoHS compliantPackage 10-TFSOP, 10-MSOP (0.118, 3.00mm Width)
Category Circuit Protection / Surge Suppression ICs
Description
IC OVERVOLT PROT REG 10-MSOP
PDF
/
Buying Options
Total Price: USD $4.83
Unit Price: USD $4.83265
≥1 USD $4.83265
≥10 USD $3.9653
≥100 USD $3.8418
≥500 USD $3.71735
≥1000 USD $3.59385
Inventory: 32875
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 3mm
Length 3mm
Height 860μm
Technical
Voltage - Working 4V~80V
Voltage - Clamping 27V Adj
Clamping Current 1.5mA
Max Input Voltage 80V
Max Output Voltage 18V
Adjustable Threshold YES
Analog IC - Other Type POWER SUPPLY SUPPORT CIRCUIT
Min Supply Voltage 4V
Max Supply Voltage 80V
Number of Circuits 1
Number of Channels 1
Max Output Current 12mA
Pin Count 10
Base Part Number LT4356
Time@Peak Reflow Temperature-Max (s) 30
Depth 3mm
Terminal Pitch 0.5mm
Supply Voltage 12V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology External Switch
Subcategory Power Management Circuits
Applications Automotive
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 10
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Published 2010
Packaging Tube
Physical
Number of Pins 10
Surface Mount YES
Package / Case 10-TFSOP, 10-MSOP (0.118, 3.00mm Width)
Mounting Type Surface Mount
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 1 week ago)
Factory Lead Time 8 Weeks
