TBU-CA040-300-WH
RoHS
RoHS compliant
RoHS compliantPackage SMD 6.50mm x 4.00mm
Category Circuit Protection / Surge Suppression ICs
Description
SURGE SUPP TBU 300MA 400VIMP SMD
PDF
/
Buying Options
Total Price: USD $1.65
Unit Price: USD $1.6456
≥1 USD $1.6456
≥10 USD $1.36576
≥100 USD $1.086712
≥500 USD $0.919512
≥1000 USD $0.78019
Inventory: 1151
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case SMD 6.50mm x 4.00mm
Number of Pins 12
Weight 2.154564g
Technical
Packaging Tape & Reel (TR)
Published 2012
Series TBU?
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
Termination Solder
Resistance 43Ohm
Terminal Finish Matte Tin (Sn)
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Applications General Purpose
Voltage - Rated 400V
Voltage - Rated DC 400V
Technology Internal Switch
Terminal Position BOTTOM
Terminal Form NO LEAD
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Current Rating 300mA
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number TBU-CA040
Pin Count 3
JESD-30 Code R-XBCC-N3
Qualification Status Not Qualified
Operating Supply Voltage 400V
Temperature Grade MILITARY
Number of Circuits 1
Element Configuration Single
Response Time 1 μs
Peak Pulse Current 600mA
Reverse Standoff Voltage 20V
Max Surge Current 450mA
Direction Bidirectional
Telecom IC Type SURGE PROTECTION CIRCUIT
ESD Protection Yes
Voltage - Working 200V
Dimensions
Height 850μm
Length 6.5mm
Width 6.5mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
