PD57-2-1160-TMCL
RoHS
RoHS compliant
RoHS compliantPackage /
Category Motors, Solenoids, Driver Boards/Modules / Stepper Motors
Description
PANdrive? 200 Hybrid 24 Stepper Motor 2.8A 0.945 24.00mm 143.05 / 1010 48VDC
PDF
/
Buying Options
Total Price: USD $264.11
Unit Price: USD $264.1056
≥1 USD $264.1056
≥10 USD $258.148
≥100 USD $253.18392
≥500 USD $248.219488
Inventory: 79
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Mounting Hole Spacing 1.856 (47.14mm)
Technical
Published 2012
Series PANdrive?
Size / Dimension Square - 2.362 x 2.362 60.00mmx60.00mm
Feature Integrated Controller, Flatted Shaft
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Wire Leads
Type Hybrid
Voltage - Rated 48VDC
Current Rating 2.8A
Termination Style Wire Leads with Connector
Coil Type Bipolar
Step Angle 1.8°
Steps per Revolution 200
Torque - Holding (oz-in / mNm) 143.05 / 1010
NEMA Frame Size 24
Dimensions
Diameter - Shaft 0.250 (6.35mm)
Length - Shaft and Bearing 0.945 24.00mm
Compliance
RoHS Status ROHS3 Compliant
