55M048D2U

Portescap
RoHS
/
Package /
Category Motors, Solenoids, Driver Boards/Modules / Stepper Motors
Description STEPPER MOTOR PM UNIPOLAR 12V
PDF
/
Inventory: 9373
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Lead Free
RoHS Status Non-RoHS Compliant

Dimensions

Length - Shaft and Bearing 0.750 19.05mm
Diameter - Shaft 0.250 (6.35mm)
Thickness 27.2mm
Diameter 55mm

Technical

Rotor Inertia 48.3gcm2
Torque - Holding (oz-in / mNm) 23 / 163
Steps per Revolution 48
Step Angle 7.5°
Coil Type Unipolar
Coil Resistance 30Ohm
Accuracy ±15%
Termination Style Wire Leads
Current Rating (Amps) 400mA
Voltage - Rated DC 12V
Type Permanent Magnet
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Obsolete
Feature Round Shaft
Size / Dimension Round - 2.170Dia 55.12mm
Series 55M
Published 2003
Operating Temperature -20°C~70°C

Physical

Mounting Hole Spacing 2.630 (66.68mm)
Weight 0.525lb 238.14g
