42M100B2U
RoHS
RoHS compliant
RoHS compliantPackage /
Category Motors, Solenoids, Driver Boards/Modules / Stepper Motors
Description
STEPPER MOTOR PM UNIPOLAR 12V
PDF
/
Buying Options
Total Price: USD $25.21
Unit Price: USD $25.212
≥1 USD $25.212
Inventory: 93
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Length - Shaft and Bearing 0.450 11.43mm
Diameter - Shaft 0.118 (3.00mm)
Thickness 22mm
Diameter 42mm
Technical
Rotor Inertia 11.8gcm2
Torque - Holding (oz-in / mNm) 6.4 / 45.2
Steps per Revolution 100
Step Angle 3.6°
Coil Type Unipolar
Coil Resistance 75Ohm
Accuracy ±11%
Termination Style Wire Leads
Current Rating (Amps) 160mA
Voltage - Rated DC 12V
Type Permanent Magnet
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Feature Round Shaft
Size / Dimension Round - 1.650Dia 42.00mm
Series 42M
Published 2003
Operating Temperature -20°C~70°C
Physical
Mounting Hole Spacing 1.950 (49.48mm)
Weight 0.193lb 87.54g
Supply Chain
Factory Lead Time 12 Weeks
