26M024D1U
RoHS
RoHS compliant
RoHS compliantPackage /
Category Motors, Solenoids, Driver Boards/Modules / Stepper Motors
Description
STEPPER MOTOR PM UNIPOLAR 5V
PDF
/
Buying Options
Total Price: USD $22.17
Unit Price: USD $22.167132
≥1 USD $22.167132
≥10 USD $20.912388
≥100 USD $19.728669
≥500 USD $18.611951
≥1000 USD $17.558443
Inventory: 1451
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Weight 0.075lb 34.02g
Mounting Hole Spacing 1.370 (34.90mm)
Technical
Operating Temperature -20°C~70°C
Published 2003
Series 26M
Size / Dimension Round - 1.030Dia 26.16mm
Feature Round Shaft
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Type Permanent Magnet
Voltage - Rated 5VDC
Current Rating (Amps) 260mA
Termination Style Wire Leads
Accuracy ±15%
Coil Resistance 19.6Ohms
Coil Type Unipolar
Step Angle 15°
Steps per Revolution 24
Torque - Holding (oz-in / mNm) 1.35 / 9.5
Rotor Inertia 1.1gcm2
Dimensions
Diameter 26mm
Thickness 13.7mm
Diameter - Shaft 0.079 (2.00mm)
Length - Shaft and Bearing 0.445 11.30mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
