23H118D10B

Portescap
RoHS
/
Package /
Category Motors, Solenoids, Driver Boards/Modules / Stepper Motors
Description STEP MOTOR HYBRID BIPOLAR 6.84V
PDF
/
Inventory: 6305
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant

Dimensions

Length - Shaft and Bearing 0.810 20.57mm
Diameter - Shaft 0.250 (6.35mm)

Technical

Rotor Inertia 240gcm2
NEMA Frame Size 23
Torque - Holding (oz-in / mNm) 180 / 1271
Steps per Revolution 200
Step Angle 1.8°
Coil Type Bipolar
Coil Resistance 6.84Ohm
Accuracy ±5%
Approval Agency CE, UL
Termination Style Wire Leads
Current Rating (Amps) 1A
Voltage - Rated 6.84VDC
Type Hybrid
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Obsolete
Feature Round Shaft
Size / Dimension Square - 2.250 x 2.250 57.15mmx57.15mm
Series H3
Published 2008
Operating Temperature -20°C~40°C

Physical

Mounting Hole Spacing 1.856 (47.14mm)
Weight 1.4lbs 635g
