17PM-K342U
RoHS
RoHS compliant
RoHS compliantPackage /
Category Motors, Solenoids, Driver Boards/Modules / Stepper Motors
Description
STEP MOTOR HYBRID UNIPOLAR 24V
PDF
/
Inventory: 9120
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Length - Shaft and Bearing 0.945 24.00mm
Diameter - Shaft 0.197 (5.00mm)
Technical
Rotor Inertia 50gcm2
NEMA Frame Size 17
Torque - Holding (oz-in / mNm) 35.41 / 250
Steps per Revolution 200
Step Angle 1.8°
Coil Type Unipolar
Coil Resistance 2Ohm
Termination Style Connector
Current Rating (Amps) 1.4A
Voltage - Rated 24VDC
Type Hybrid
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Round Shaft
Size / Dimension Square - 1.654 x 1.654 42.00mmx42.00mm
Series 17PM
Physical
Mounting Hole Spacing 1.220 (31.00mm)
Supply Chain
Factory Lead Time 8 Weeks
