WO-4209S-01P
RoHS
RoHS compliant
RoHS compliantPackage /
Category Motors, Solenoids, Driver Boards/Modules / Stepper Motors
Description
STEPPER MOTOR
PDF
/
Buying Options
Total Price: USD $34.28
Unit Price: USD $34.276355
≥1 USD $34.276355
≥10 USD $32.336183
≥100 USD $30.505834
≥500 USD $28.779091
≥1000 USD $27.150088
Inventory: 3253
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mounting Hole Spacing 1.220 (31.00mm)
Technical
Operating Temperature -20°C~50°C
Packaging Tray
Size / Dimension Square - 1.669 x 1.669 42.40mmx42.40mm
Feature Double Round Shaft
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Voltage - Rated 24VDC
Current Rating (Amps) 1.33A
Termination Style Wire Leads
Coil Resistance 2.4Ohm
Coil Type Bipolar
Step Angle 0.9°
Steps per Revolution 400
Torque - Holding (oz-in / mNm) 31 / 219
NEMA Frame Size 17
Rotor Inertia 0.835gcm2
Dimensions
Diameter - Shaft 0.197 (5.00mm)
Length - Shaft and Bearing 0.945 24.00mm
Compliance
RoHS Status RoHS Compliant
