WO-4118L-07S

LIN Engineering
RoHS
RoHS RoHS compliant
Package /
Category Motors, Solenoids, Driver Boards/Modules / Stepper Motors
Description STEPPER MOTOR
PDF
/
Buying Options
Total Price: USD $50.2
Unit Price: USD $50.1952
≥1 USD $50.1952
≥10 USD $49.33104
≥100 USD $48.466
≥500 USD $47.600854
≥1000 USD $46.73533
≥3000 USD $46.042946
Inventory: 45
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status RoHS Compliant

Dimensions

Length - Shaft and Bearing 0.945 24.00mm
Diameter - Shaft 0.197 (5.00mm)

Technical

Rotor Inertia 1.6gcm2
NEMA Frame Size 17
Torque - Holding (oz-in / mNm) 83 / 586.11
Steps per Revolution 200
Step Angle 1.8°
Coil Type Bipolar
Coil Resistance 5.2Ohm
Termination Style Wire Leads
Current Rating (Amps) 1.05A
Voltage - Rated 24VDC
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Flatted Shaft
Size / Dimension Square - 1.669 x 1.669 42.40mmx42.40mm
Packaging Tray
Operating Temperature -20°C~50°C

Physical

Mounting Hole Spacing 1.220 (31.00mm)

Supply Chain

Factory Lead Time 16 Weeks
