WO-4109X-51
RoHS
RoHS compliant
RoHS compliantPackage /
Category Motors, Solenoids, Driver Boards/Modules / Stepper Motors
Description
STEPPER MOTOR
PDF
/
Buying Options
Total Price: USD $39.71
Unit Price: USD $39.7056
≥1 USD $39.7056
≥10 USD $39.02272
≥100 USD $38.3372
Inventory: 102
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mounting Hole Spacing 1.220 (31.00mm)
Technical
Operating Temperature -20°C~50°C
Packaging Tray
Size / Dimension Square - 1.654 x 1.654 42.00mmx42.00mm
Feature Double Round Shaft
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Voltage - Rated 24VDC
Current Rating (Amps) 600mA
Termination Style Wire Leads
Coil Resistance 5Ohm
Coil Type Bipolar
Step Angle 0.9°
Steps per Revolution 400
Torque - Holding (oz-in / mNm) 7 / 49.4
NEMA Frame Size 17
Rotor Inertia 0.176gcm2
Dimensions
Diameter - Shaft 0.197 (5.00mm)
Length - Shaft and Bearing 0.591 15.00mm
Compliance
RoHS Status RoHS Compliant
