PM42S-075-085
RoHS
RoHS compliant
RoHS compliantPackage /
Category Motors, Solenoids, Driver Boards/Modules / Stepper Motors
Description
PERMANENT MAGNET STEPPER MOTOR
PDF
/
Inventory: 8839
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Length - Shaft and Bearing 0.394 10.00mm
Diameter - Shaft 0.118 (3.00mm)
Technical
Rotor Inertia 7.2gcm2
Steps per Revolution 48
Step Angle 7.5°
Coil Type Bipolar
Coil Resistance 5.4Ohm
Termination Style Wire Leads with Connector
Voltage - Rated 24VDC
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension Round - 1.650Dia 42.00mm
Packaging Tray
Operating Temperature -20°C~50°C
Physical
Mounting Hole Spacing 1.949 (49.50mm)
Supply Chain
Factory Lead Time 16 Weeks
