PM42L-075-065

LIN Engineering
RoHS
RoHS RoHS compliant
Package /
Category Motors, Solenoids, Driver Boards/Modules / Stepper Motors
Description PERMANENT MAGNET STEPPER MOTOR
PDF
/
Inventory: 1817
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant

Dimensions

Length - Shaft and Bearing 0.394 10.00mm
Diameter - Shaft 0.118 (3.00mm)

Technical

Rotor Inertia 11.6gcm2
Torque - Holding (oz-in / mNm) 13.2 / 93.21
Steps per Revolution 48
Step Angle 7.5°
Coil Type Bipolar
Coil Resistance 3.2Ohm
Termination Style Wire Leads with Connector
Current Rating (Amps) 0.85A
Voltage - Rated 24VDC
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension Round - 1.650Dia 42.00mm
Packaging Tray
Operating Temperature -20°C~50°C

Physical

Mounting Hole Spacing 1.949 (49.50mm)

Supply Chain

Factory Lead Time 16 Weeks
