PM25S-075-047
RoHS
RoHS compliant
RoHS compliantPackage /
Category Motors, Solenoids, Driver Boards/Modules / Stepper Motors
Description
PERMANENT MAGNET STEPPER MOTOR
PDF
/
Buying Options
Total Price: USD $48.9
Unit Price: USD $48.898082
≥1 USD $48.898082
≥10 USD $46.130264
≥100 USD $43.519118
≥500 USD $41.055769
≥1000 USD $38.731858
Inventory: 1528
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mounting Hole Spacing 1.260 (32.00mm)
Technical
Operating Temperature -20°C~50°C
Packaging Tray
Size / Dimension Round - 0.984Dia 25.00mm
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Voltage - Rated 12VDC
Current Rating (Amps) 0.5A
Termination Style Wire Leads with Connector
Coil Resistance 6Ohm
Coil Type Bipolar
Step Angle 7.5°
Steps per Revolution 48
Torque - Holding (oz-in / mNm) 2.2 / 15.7
Rotor Inertia 0.54gcm2
Dimensions
Diameter - Shaft 0.079 (2.00mm)
Length - Shaft and Bearing 0.394 10.00mm
Compliance
RoHS Status RoHS Compliant
