PM25L-075-050
RoHS
RoHS compliant
RoHS compliantPackage /
Category Motors, Solenoids, Driver Boards/Modules / Stepper Motors
Description
PERMANENT MAGNET STEPPER MOTOR
PDF
/
Inventory: 4481
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mounting Hole Spacing 1.260 (32.00mm)
Technical
Operating Temperature -20°C~50°C
Packaging Tray
Size / Dimension Round - 0.591Dia 15.00mm
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Voltage - Rated 12VDC
Current Rating (Amps) 0.47A
Termination Style Wire Leads with Connector
Coil Resistance 8Ohm
Coil Type Bipolar
Step Angle 7.5°
Steps per Revolution 48
Torque - Holding (oz-in / mNm) 35.41 / 250
Dimensions
Diameter - Shaft 0.079 (2.00mm)
Length - Shaft and Bearing 0.394 10.00mm
Compliance
RoHS Status RoHS Compliant
