82924051
RoHS
RoHS compliant
RoHS compliantPackage /
Category Motors, Solenoids, Driver Boards/Modules / Stepper Motors
Description
82924 48 Permanent Magnet Gear Motor 21 Stepper Motor 280mA 0.520 13.20mm 9.91 / 70 6.3VDC
PDF
/
Inventory: 6485
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Length - Shaft and Bearing 0.520 13.20mm
Diameter - Shaft 0.157 (4.00mm)
Technical
Rotor Inertia 18.8gcm2
NEMA Frame Size 21
Torque - Holding (oz-in / mNm) 9.91 / 70
Steps per Revolution 48
Step Angle 7.5°
Coil Type Unipolar
Coil Resistance 46Ohm
Accuracy ±5%
Termination Style Wire Leads
Current Rating (Amps) 280mA
Voltage - Rated 6.3VDC
Type Permanent Magnet Gear Motor
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Flatted Shaft
Size / Dimension Round - 2.020Dia 51.30mm
Series 82924
Operating Temperature -30°C~70°C
Physical
Mounting Hole Spacing 1.874 (47.60mm)
Weight 0.463lb 210.01g
Supply Chain
Factory Lead Time 13 Weeks
