Crouzet
RoHS
RoHS RoHS compliant
Package /
Category Motors, Solenoids, Driver Boards/Modules / Stepper Motors
Description STEPPER MOTOR PM GEARED UNI 6.3V
PDF
/
Inventory: 5658
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 13 Weeks

Physical

Weight 0.463lb 210.01g
Mounting Hole Spacing 1.874 (47.60mm)

Technical

Operating Temperature -30°C~70°C
Series 82924
Size / Dimension Round - 2.020Dia 51.30mm
Feature Flatted Shaft
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Permanent Magnet Gear Motor
Voltage - Rated 6.3VDC
Current Rating (Amps) 590mA
Termination Style Wire Leads
Accuracy ±5%
Coil Resistance 10.7Ohm
Coil Type Unipolar
Step Angle 7.5°
Steps per Revolution 48
Torque - Holding (oz-in / mNm) 9.91 / 70
NEMA Frame Size 21
Rotor Inertia 18.8gcm2

Dimensions

Diameter - Shaft 0.157 (4.00mm)
Length - Shaft and Bearing 0.520 13.20mm

Compliance

RoHS Status RoHS Compliant
