PH9400.122NLT
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Specialty Transformers
Description
XFMR GATE DRIVE SIDE CAR SMT
PDF
/
Buying Options
Total Price: USD $4.06
Unit Price: USD $4.0568
≥1 USD $4.0568
≥10 USD $3.28944
≥100 USD $2.659712
≥500 USD $2.491808
Inventory: 424
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Height Seated (Max) 0.559 14.20mm
Height 14.2mm
Technical
Transformer Type PULSE TRANSFORMER
Isolation Voltage 4kV
Inductance 2.88mH
Capacitance 60pF
Min Operating Temperature -40°C
Max Operating Temperature 125°C
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.657Lx0.500W 16.70mmx12.70mm
Series PH9400
Packaging Tape & Reel (TR)
Physical
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 11 Weeks
