PH9185.034NL
RoHS
RoHS compliant
RoHS compliantPackage SMD/SMT
Category Transformers / Specialty Transformers
Description
Power Transformers TRANSFORMER 750UH 3:4 SMD
PDF
/
Buying Options
Total Price: USD $3.81
Unit Price: USD $3.8104
≥1 USD $3.8104
≥10 USD $3.09144
≥100 USD $2.4992
≥500 USD $2.34146
≥1000 USD $2.236194
≥3000 USD $2.17045
Inventory: 895
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 10.01mm
Length 10.01mm
Height Seated (Max) 0.492 12.50mm
Height 12.5mm
Technical
Number of Primary Winding 1
Number of Secondary Winding 1
Turns Ratio - Primary:Secondary 3:4
Transformer Type SMPS TRANSFORMER
Isolation Voltage 5kV
Inductance 750μH
Physical Dimension L10.01XB10.01XH12.5 (mm)
Capacitance 10pF
Additional Feature HEIGHT DIMENSION INCLUDES TERMINAL ALSO, TURNS RATIO: 3CT:4CT
Min Operating Temperature -40°C
Max Operating Temperature 125°C
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.394Lx0.394W 10.00mmx10.00mm
Series PH9185
Packaging Tray
Physical
Weight 0.006lb 2.72g
Package / Case SMD/SMT
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 11 Weeks
