PH9185.012NL image
Favorite
PH9185.012NL image
Favorite
RoHS
RoHS RoHS compliant
Package SMD/SMT
Category Transformers / Specialty Transformers
Description Power Transformers TRANSFORMER 450UH 1:2 SMD
PDF
/
Buying Options
Total Price: USD $4
Unit Price: USD $4.004
≥1 USD $4.004
≥10 USD $3.24544
≥100 USD $2.62416
≥500 USD $2.4585
≥1000 USD $2.34806
≥3000 USD $2.27898
Inventory: 5006
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 11 Weeks

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case SMD/SMT
Number of Pins 6
Weight 0.006lb 2.72g

Technical

Packaging Tray
Series PH9185
Size / Dimension 0.394Lx0.394W 10.00mmx10.00mm
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Capacitance 10pF
Depth 13mm
Inductance 450μH
DC Resistance (DCR) 400mOhm
Lead/Base Style Gull Wing
Isolation Voltage 5kV
Transformer Type SMPS TRANSFORMER
Turns Ratio - Primary:Secondary 1:2

Dimensions

Height 12.5mm
Height Seated (Max) 0.492 12.50mm

Compliance

RoHS Status RoHS Compliant
