PE-8270
RoHS
/
Package DIP
Category Transformers / Specialty Transformers
Description
Pulse Transformers THT General Purpose 2000uH 2.5Ohms
PDF
/
Buying Options
Total Price: USD $23.79
Unit Price: USD $23.7918
≥1 USD $23.7918
≥10 USD $19.52155
≥100 USD $18.91165
≥500 USD $18.30175
≥1000 USD $17.69185
Inventory: 5510
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Dimensions
Width 8.89mm
Height Seated (Max) 0.250 6.35mm
Height 6.35mm
Technical
Turns Ratio - Primary:Secondary 1:1
Transformer Type PULSE TRANSFORMER
Isolation Voltage 700V
Application GENERAL PURPOSE
Lead/Base Style PC Pin
DC Resistance (DCR) 2.5Ohm
Inductance 2mH
Depth 12.7mm
Number of Functions 1
Power Rating 500mW
Min Operating Temperature 0°C
Max Operating Temperature 70°C
ECCN Code EAR99
Termination Radial
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Size / Dimension 0.500Lx0.350W 12.70mmx8.89mm
Published 2007
Packaging Tube
Physical
Number of Pins 6
Package / Case DIP
Mounting Type Through Hole
Mount Through Hole
