CTX210605TR-R image
Favorite
CTX210605TR-R image
Favorite
RoHS
/
Package /
Category Transformers / Specialty Transformers
Description TRANSFORMER CCFL 6W 20V 11MA SMD
PDF
/
Inventory: 8539
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant
Radiation Hardening No

Dimensions

Width 16.5mm
Length 21mm
Height Seated (Max) 0.217 5.50mm

Technical

Turns Ratio - Primary:Secondary 1:67
Primary Winding(s) Dual
Transformer Type INVERTER TRANSFORMER
Operating Frequency-Max 80kHz
Input Voltage (Max) 20V
Output Voltage 1 1340V
Lead/Base Style Gull Wing
Element Configuration Single
Inductance 44μH
Depth 26mm
Power Rating 6W
Additional Feature HEIGHT DIMENSION INCLUDES TERMINAL ALSO
Min Operating Temperature 0°C
Max Operating Temperature 70°C
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Size / Dimension 0.650Lx0.827W 16.50mmx21.00mm
Published 2014
Packaging Tape & Reel (TR)

Physical

Weight 7.257478g
Number of Pins 7
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Factory Lead Time 19 Weeks
