MAX30102EFD+T
RoHS
RoHS compliant
RoHS compliantPackage /
Category Sensors, Transducers / Specialized Sensors
Description
INTEGRATED OPTICAL SENSOR
PDF
/
Buying Options
Total Price: USD $9.57
Unit Price: USD $9.5744
≥1 USD $9.5744
≥10 USD $8.8
≥100 USD $8.435328
≥500 USD $7.43204
≥1000 USD $7.06728
≥3000 USD $6.611334
Inventory: 8614
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 3.3mm
Length 5.6mm
Height Seated (Max) 1.65mm
Technical
Sensor Type Oximeter/Heart Rate
Analog IC - Other Type ANALOG CIRCUIT
Supply Voltage-Min (Vsup) 1.7V
Supply Voltage-Max (Vsup) 2V
Output Type I2C
JESD-30 Code R-XBGA-B14
Base Part Number MAX30102
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 0.8mm
Supply Voltage 1.8V
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form BUTT
Terminal Position BOTTOM
HTS Code 8542.39.00.01
Additional Feature IT ALSO REQUIRES 3.3 V SUPPLY
Number of Terminations 14
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Published 2012
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Surface Mount YES
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 1 month ago)
Factory Lead Time 16 Weeks
