GW10J7K50E
RoHS
RoHS compliant
RoHS compliantPackage /
Category Resistors / Specialized Resistors
Description
G 10W 7.5kOhm ±100ppm/C ±5%
PDF
/
Buying Options
Total Price: USD $3.57
Unit Price: USD $3.5728
≥1 USD $3.5728
Inventory: 926
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Length 22mm
Diameter 9.5mm
Technical
Construction Cylindrical
Terminal Pitch 22mm
Technology WIRE WOUND
Max Power Dissipation 10W
Voltage - Rated DC 685V
Power Rating 10W
Subcategory Fixed Resistors
Voltage - Rated 685V
Applications Capacitor Discharge
Composition Wirewound
Resistance 7.5kOhm
Type Bleeder, Capacitor
Temperature Coefficient ±100ppm/°C
ECCN Code EAR99
Termination Solder
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Tolerance ±5%
Series G
Published 2007
Packaging Bulk
Operating Temperature -55°C~200°C
Physical
Number of Pins 2
Terminal Shape LUG
Mounting Type Capacitor, 22mm Pitch
Mount Flanges
Supply Chain
Factory Lead Time 20 Weeks
