STV0974E/TR
RoHS
RoHS compliant
RoHS compliantPackage 56-TFBGA
Category Integrated Circuits (ICs) / Specialized ICs
Description
IC DSP IMAGING VGA CMOS 6X6TFBGA
PDF
/
Inventory: 1395
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 6mm
Length 6mm
Height Seated (Max) 1.2mm
Technical
Supply Voltage-Min (Vsup) 1.7V
Temperature Grade OTHER
Power Supplies 1.8V
Supply Voltage-Max (Vsup) 1.9V
Qualification Status Not Qualified
Pin Count 56
Base Part Number STV0974
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 0.5mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form BALL
Terminal Position BOTTOM
Subcategory Other Consumer ICs
HTS Code 8542.39.00.01
Applications Cell Phones, Digital Cameras, Media Players
Min Operating Temperature -25°C
Max Operating Temperature 70°C
Terminal Finish Tin/Silver/Copper (Sn95.5Ag4.0Cu0.5)
Type DSP
Number of Terminations 56
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e1
Packaging Tape & Reel (TR)
Physical
Number of Pins 56
Package / Case 56-TFBGA
Mounting Type Surface Mount
Mount Surface Mount
